API 5L Carbon Seamless Steel Pipes

API 5L Carbon Seamless Steel Pipes

API 5L Carbon Seamless Steel Pipes
API 5L Carbon Seamless Steel PipesAPI 5L Carbon Seamless Steel PipesAPI 5L Carbon Seamless Steel PipesAPI 5L Carbon Seamless Steel PipesAPI 5L Carbon Seamless Steel Pipes
CategoriesCarbon Seamless Pipe
BrandBAOLAI Steel Pipe Wholesale Manufacturer
ModelAPI 5L
CertificationAPI
GradeGr.B/ X42/ X52/ X60/ X65
Out Diameter1/2" - 48" ( DN15 - DN1200)
Wall ThicknessSch40/ 80/ 120/ 160
Length6M/12M or Customized
EndsPlain/ Bevel
UsageOil and Gas/ Water Pipeline
SurfaceBare/ Black/ Varnish/ Oiled/ Galvanized, 3PE, etc
Download DOCpdf icon
Update TimeNovember 27,2022
Detail Information
Specification
API 5L Seamless Steel Tube
We are one of the biggest manufactures of steel & stainless steel & alloy steel tubes and pipes in China. With development more than 30 years, we have accumulated a great many clients all around the world and BAOLAI products also won the great praise among the customers. Please feel free to send your requirements to us: info@baolaisteel.com.

API 5L pipeline is the oil, natural gas and water transmission pipeline specified by American Petroleum Institute, including seamless and welded steel pipes.


API 5L line pipes are available in multiple carbon steel grades, designated as Grade B, X42, X46, X52, X56, X60, X70, X80 and in PSL1 or PSL2 specification levels.  The following is the difference between PSL1 and PSL2 and the introduction of common steel grades.
Advantage of API 5L Seamless Pipeline
API 5L Seamless Pipeline stock

Help cut down on expenses.
Athough more expensive than welded pipe,but this increased ability to withstand pressure allows to use pipes that are thinner and lighter,
so the total price is lower.
API 5L Seamless Pipe stock

Excellent resistance to cracking forces which can be caused in long pipelines;Sour service suitability and durable;Excellent strength and ability to withstand in high-temperature applications;Long service life in any industrial pipeline operation.
API 5L pipe
API 5L pipe
API 5L pipe
API 5L pipe
Differences between PSL1 & PSL2
NPS
Outside Diameter
Wall Thickness
CVN impact (Charpy) testing
None required
Required for all grades
Nondestructive Inspection of Seamless
Only when purchaser specifies SR4
SR4 mandatory
Certification
Certificates when specified per SR15
Certificates (SR 15.1) mandatory
Traceability
Traceable only until all tests are passed, unless SR15 is specified
Traceable after completion of tests (SR 15.2) mandatory
Hydrostatic Test
Required
Required
Application of API 5L Seamless Tube Common Grades
API 5L pipe
API 5L Gr.B
Gr.B is the most used steel grade in API 5L, which is used for for low pressure fluid lines and serving different mediums, such as the transmission of oil, natural gas, or water.
API 5L pipe
API 5L X60/X65
API 5L X60/X65 pipeline are also common grade mostly used in the petroleum and oil and gas industries.
API 5L pipe
API 5L X42
API 5L X42 line pipe is most commonly used in the petroleum industry to transport oil and gas.
Onshore, for transporting oil and gas from wellheads to refineries, and offshore, for transporting oil and gas from platforms to onshore terminals.
API 5L X42 line pipe is also used in other industries such as chemical industry, for chemical transportation, construction industry, for pipeline construction.
API 5L pipe
API 5L X52
X52 and X42 have the same purpose, but the impact test of - 20 ° is added to X42.
So it is a higher strength steel grade than X42 and is typically used in higher-pressure applications.
At present, the demand for API 5L X52 steel pipes in African countries is increasing.
Example Size
Note: Some of the main specifications are shown below, please contact us for more details.
Download API 5L for full specifications
NPS
Designator
DN
Designator
Outside Diameter
Wall Thickness
Weight Class
Schedule
No.
Test Pressure, psi
mm
mm
Grade A
Grade B
1/2"
15
21.3
2.77
STD
40
4.8
4.8
3.73
XS
80
5.9
5.9
4.78
-
160
6.2
6.2
7.47
XXS
-
6.9
6.9
6"
150
168.3
4.78
-
-
7.0
8.2
5.56
-
-
8.2
9.6
6.35
-
-
9.4
10.9
7.11
STD
40
10.5
13.0
7.92
-
-
11.7
13.7
8.74
-
-
12.9
15.0
9.52
-
-
14.1
16.4
10.97
XS
80
16.2
18.9
